View Cart1992-93 Chevrolet Cavalier Convertible Top and Convertible Top Parts
Important Information | New: Custom Fit Car Covers
Fabrics:
The original Chevrolet Cavalier convertible top fabric was Haartz Pinpoint vinyl in most original dealer tops. Many 92-93 tops were made in black Haartz Stayfast canvas. Pinpoint is a classic fabric that was used on most American convertible tops from the fifties through the nineties.
Haartz Stayfast canvas is chosen by some restorers. It is the most durable of toppings. Please consult the 'Help' link above and select 'Convertible Top Fabrics' to read detailed information about these and other toppings. Contact us if you want a custom top in any other fabric.
Do-It-Yourself Installation:
These convertible tops are classic two part tops. That means that the rear window section and the main top are two separate sections. They are integrated by the stapling that is done in the installation process. You can read the summary of our two part top installation manual via the blue link below.
This summary will allow you to decide whether to perform your own installation. We have a 20 page illustrated, step by step installation manual for 80s and 90s Cavaliers. This should allow the patient, handy, person to install his/her own top. The installation involves stapling and use of contact cement. There is no sewing.
Package Special:
Our package special is designed for the do-it-yourself complete top restoration. If you wish to order some, but not all, of the items in the package, please email us at support@mtmfg.com for a revised package quotation.
Hold Down Cables:
These fasten the top along the sides to the top frame. Cables thread through special pockets built into the inner edges of the main top.
Top Pads:
Pads, under the top, can last through two or more tops. They can be examined upon removal of the old top and retained if undamaged.
Well Liner:
The rear well liner is shaped to fit your car's well area. A pre-made well liner saves much measuring and cutting time. However an undamaged rear well liner may be left in place. Rear well liners, may last through several tops.
Tack Strips:
Tacking strips embedded into the front bow and the rear top bow, as well as smaller strips in the corners of the intermediate bows, receive the staples or tacks. Tack strips should last through two or even three tops.
There is a rear base line tacking bow set too. This assembly should last through several tops. Please inquire if you need help replacing your rear base tack bow set.
Hydraulics:
We now stock hydraulic cylinders, motor-pumps, and hoses for your convertible tops. All are made to OEM specifications. Each can be ordered separately; however, when ordering hydraulic cylinders we recommend replacing both. The chances are that both hydraulic cylinders were manufactured at the same time: if one is on its way out the other may follow. If the top is raised and one hydraulic cylinder is working harder than the other the result over time can lead to a slightly bent convertible top frame. The replacement of both hydraulic cylinders will ensure that the top raises and lowers symmetrically.
Systems for this car take Automatic Transmission Fluid (ATF) and have a 5 year warranty when used with this fluid. Brake fluid should not be used as it voids the warranty. We also offer an installation manual when ordered.
The 12 volt motor-pumps include a mounting bracket with rubber grommets to reduce vibration.
We also offer a rebuilding service for motor-pumps. Not all are repairable, but it is less expensive to have one rebuilt than to buy a new one. The motor-pump would need to be sent to us for evaluation. Hoses come with all new fittings and are made specifically to fit your car.
Covercraft Custom Fit Car Covers
Since 1965 Covercraft has pioneered the market for custom fit vehicle car covers and today are the largest manufacturer of custom-patterned vehicle covers in the world. They have over 67,000 patterns, and are continually growing. Still family owned, Covercraft has always maintained the highest standards, utilized the finest materials and remained on the cutting of manufacturing technology.
Parts in this category (Chevrolet Cavalier) fit cars for years: 1992 and 1993.
We a now pleased to offer hydraulic cylinders, hydraulic motor pumps, and hydraulic hose sets. Also, checkout our newly added roof rail weatherstripping seals, front header weatherstripping seals, door weatherstripping seals, trunk weatherstripping seals. Look for extra savings on weatherstripping seals kits.
